Details
Road or Gravel? 5 miles or 5 hours? Climb or Descend? Suffer or Smile? More power or less weight?
The Creo 2 isn't about having to choose. It's about having it all. With more power, a big range, lightweight, huge tire clearance, and Future Shock 3.0, it's category-defying making previously impossible rides possible.
- CLASS-LEADING AMPLIFICATION:
The all-new TURBO SL 1.2 system delivers industry-leading efficiency for a range of up to 120 miles. It creates 33% more power (320 Watts) than its predecessor and delivers that power across an ideal pedaling cadence for a supernatural feel. With 43% more torque (50Nm), the power comes on instantly—making quick work of the steepest hills. But less is more when it comes to noise, so we reduced dBs by 40%. It's literally whisper quiet.
- RE-TIRED FOR CONFIDENCE:
700 x 47c Tires Spec'd but up to 29" x 2.2" Tire Clearance. The big tire volume delivers a smooth and confident ride on the roughest terrain. And with the Creo 2's power, you can take all that tire volume to the road with no penalty for a next-level silky ride.
- FUTURE SHOCK 3.0:
The Creo 2 features Future Shock 3.0 with 20mm of smooth travel at the handlebars that reduce impacts by 53%. Future Shock helps keep your hands and bars steady for a smoother ride with more control to stay fast, safe, and confident—all while helping reduce fatigue over long days in the saddle.
- THE GEOMETRY OF CAPABILITY:
The Creo 2 boasts our most progressive geometry yet that will have you ripping everything from wide open roads to dicey gravel tracks with ultimate confidence. A more ergonomic endurance position feels great, with the power to ride all day.
- TUNE IN, TURN ON, DROP 'ER DOWN:
Lower your center of gravity with the dropper post for enhanced corning and control in any terrain.
- LOAD UP, HEAD OUT:
Take a little or a lot on any ride. Creo 2 accepts a variety of front, rear, and low-rider racks. Who says you can't take it all?
- YOU'RE IN CONTROL:
Our most advanced and intuitive e-bike control unit. Connecting the bike, the Turbo OS, the Specialized App, and the rider, all in a protected and easily visible display. With MicroTune, fine-tuning power output levels in real-time is at your fingertips, optimizing your range management and performance.
- MASTERMIND TCU:
The MasterMind TCU is the brain of the bike. Displaying all relevant info about your ride, it allows real-time tuning of support levels, enables over-the-air updates so that your bike gets better over time, and seamlessly integrates with the Specialized app for advanced tuning, on-trail diagnostics, customizable display, and more.
- ALL-NEW SPECIALIZED APP:
The Creo 2 integrates fully with our Specialized App and lets you personalize your motor characteristics. You can record your rides, personalize your screens, track your data, synch with other apps, and even thwart would-be thieves with Turbo System Auto-Lock.
Frame Size | 49 | 52 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Stack (mm) | 578 | 578 | 595 | 607 | 638 | 663 |
Reach (mm) | 365 | 374 | 383 | 392 | 401 | 410 |
Head-Tube Length (mm) | 90 | 90 | 108 | 120 | 153 | 180 |
Head-Tube Angle (degrees) | 71 | 71 | 71 | 71 | 71 | 71 |
B-B Height (mm) | 270 | 270 | 270 | 270 | 270 | 270 |
B-B Drop (mm) | 80 | 80 | 80 | 80 | 80 | 80 |
Trail (mm) | 62 | 62 | 62 | 62 | 62 | 62 |
Fork Length (full) (mm) | 405 | 405 | 405 | 405 | 405 | 405 |
Fork Rake / Offset (mm) | 55 | 55 | 55 | 55 | 55 | 55 |
Front-Center (mm) | 600.1 | 609 | 623.8 | 636.6 | 656.2 | 673.8 |
Chain-Stay Length (mm) | 435 | 435 | 435 | 435 | 435 | 435 |
Wheelbase (mm) | 1022 | 1031 | 1046 | 1059 | 1079 | 1097 |
Top-Tube Length (horizontal) (mm) | 531 | 540 | 554 | 572 | 590 | 613 |
Bike Stand-Over Height (mm) | 731 | 743 | 773 | 793 | 824 | 852 |
Seat-Tube Length (mm) | 410 | 430 | 470 | 500 | 530 | 560 |
Seat-Tube Angle (degrees) | 74 | 74 | 74 | 73.5 | 73.5 | 73 |
Crank Length (mm) | 165 | 170 | 172.5 | 172.5 | 175 | 175 |
Handlebar Width (mm) | 380 | 400 | 420 | 420 | 440 | 440 |
Stem Length (mm) | 60 | 70 | 80 | 90 | 100 | 100 |
Frame Size | Rider Height (in) | Rider Height (cm) |
---|---|---|
49 | 5'1" - 5'4" | 155 - 158 |
52 | 5'4" - 5'6" | 163 - 168 |
54 | 5'6" - 5'9" | 168 - 175 |
56 | 5'9" - 6'0" | 175 - 183 |
58 | 6'0" - 6'3" | 183 - 191 |
61 | 6'3" - 6'6" | 191 - 198 |
Specs
Frame | FACT 11r carbon, front/rear thru-axles, fully integrated down tube battery, internal cable routing, fender/rack mounts, 12x142mm |
---|---|
Fork | Future Shock 3.2 w/ Smooth Boot, 12x100mm thru-axle, flat-mount disc |
Wheels |
Front: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples Rear: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples |
Tires |
Front: Tracer Pro, 700x47c Rear: Tracer Pro, 700x47c |
Crankset | SRAM Alloy DUB Crank Arms |
Chainrings | SRAM X-Sync Eagle, 107 BCD, 44T |
Shifters | SRAM Apex eTap AXS |
Rear Derailleur | SRAM X1 Eagle AXS |
Cassette/Freewheel | SRAM PG1210, 12-Speed, 11-50t |
Chain | SRAM NX Eagle, 12-Speed |
Brakes |
Front: SRAM Apex eTAP AXS, hydraulic disc Rear: SRAM Apex eTAP AXS, hydraulic disc |
Handlebars | Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12o flare |
Tape/Grips | Supacaz Super Sticky Kush |
Stem | Future Stem Comp |
Seatpost | Trans-X Dropper, 50mm Travel |
Saddle | Body Geometry Power Sport |
Pedals | Sold Separately |
Accessories & Extras | Custom Specialized wiring harness w/ charge port |
Motor | New Specialized 1.2 SL Custom Lightweight Motor |
Battery | Specialized SL1-320, fully integrated, 320Wh |
Controller/Display | Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote |
Charger | Custom charger, 48V System w/ SL system charger plug |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Deep Lake Metallic/ Deep Lake / 49 | 888818803798 | 98123-5149 | |
Deep Lake Metallic/ Deep Lake / 52 | 888818803958 | 98123-5152 | |
Deep Lake Metallic/ Deep Lake / 54 | 888818804641 | 98123-5154 | 210000009901 |
Deep Lake Metallic/ Deep Lake / 56 | 888818804122 | 98123-5156 | 210000009828 |
Deep Lake Metallic/ Deep Lake / 58 | 888818805259 | 98123-5158 | |
Deep Lake Metallic/ Deep Lake / 61 | 888818803552 | 98123-5161 | |
Harvest Gold/Harvest Gold Tint / 49 | 888818805167 | 98123-5049 | |
Harvest Gold/Harvest Gold Tint / 52 | 888818804412 | 98123-5052 | |
Harvest Gold/Harvest Gold Tint / 54 | 888818803750 | 98123-5054 | 210000010438 |
Harvest Gold/Harvest Gold Tint / 56 | 888818804399 | 98123-5056 | |
Harvest Gold/Harvest Gold Tint / 58 | 888818805068 | 98123-5058 | |
Harvest Gold/Harvest Gold Tint / 61 | 888818803835 | 98123-5061 |
